Panasonic LUMIX S1H

Item No.: NC1601
Description Specification
Description: The world's first mirrorless camera capable of video recording at 6K / 24p (3: 2 aspect ratio), 5.9K / 30p (16: 9 aspect ratio) and 10-bit 60p 4K / C4K. The newly developed 24.2 megapixel full-frame image sensor uses the new dual-native ISO standard. Combined with a powerful signal processing Venus engine, it achieves ultra-high sensitivity and minimizes noise.

Feature:
1. Professional video recording performance
2. High reliability, support professional work
3. create freedom, scalability
4. High operability and intuitive control
5. The best choice for digital still photos

Image sensor
Type: CMOS
Size: 35.6×23.8mm
Total Pixels: 25.28megapixels
Effective Pixels: 24.20megapixels
Image Processor: Venus Engine
Color Space: sRGB, AdobeRGB
Image Format: JPEG, RAW, HLG
Image Size: When using a full-frame lens, 3: 2: 6000x4000 (L) / 4272x2848 (M) / 3024x2016 (S) / 12000x8000 (XL) * * High-resolution mode. RAW file 5184x3456 (6K photo) / 3504x2336 (4K photo) / 5984x4000 (HLG photo, full resolution) / 3232x2160 (HLG photo, 4K resolution)
Image Quality: RAW / RAW + Fine / RAW + Standard / Fine / Standard
Frame Ratio: 3:2, 4:3, 16:9, 1:1, 65:24, 2:1
Movie Format: MOV, MP4
Movie Size: 6K / 24p,5.4K / 30p,5.9K / 30p
Video Format: MOVLPCM2ch 48 kHz/16 bit48 kHz/24 bit96 kHz/24 bit
MP4
ACC2ch
Anti ShakeSystem: Body I.S. (5-axis) and O.I.S. (optical image stabilizer, 2-axis)
Dust removal system: Supersonic filter

Lens and Focus
Lens Mount: Leica L
Focusing Type: Contrast autofocus system
AF ModesAFs (single) AFc (continues) MF
AF Assist Lamp: Yes
Manuel Focusing: supported

Exposure Control
Metering System: 1,728 area multiple pattern sensing system
Metering Mode: Center-weighted, spot, multi-meter, highlight-weighted
Metering Range: 0EV~18EV
Exposure Mode: Program AE / Aperture-Priority AE / Shutter-Priority AE / Manual Exposure
Creative Filter: Expressive Nostalgic Nostalgia Old Time High Key Tone Dark Tone   Dark Brown Monochrome Dynamic Monochrome Granular Monochrome    Smooth Monochrome  Impression Art  High Dynamic Positive Negative Charge   Toy Camera Effect  Vivid Toy Camera Bleaching Effect Miniature Effect Soft Focus    Illusion  Starlight Filter  Single Point Color   Sunlight Only for Photos
Shutter Type: Focal plane shutter
Shutter Speed: Still image: Bulb (up to 30 minutes), 1/8000-60
Electronic front curtain shutter: Bulb (up to 30 minutes), 1/2000-60
Electronic shutter: Bulb (up to 60 seconds), 1/8000-60
Motion picture: 1 / 16,000-1/25 (when using sync scan)
Creative Video M Mode / MF Mode: 1 / 16,000-1/2
Exposure Compensation: ± 5EV in 1 / 3EV steps
Auto Exposure Bracketing: 1/3, 2/3, or 1 EV steps are 3, 5, or 7 images, maximum ± 3 EV, single / continuous
ISO: Auto / 50 * / 100/200/400/800/1600/3200/6400/12800/25600/51200/102400 * / 204800 * (can be changed to 1/3 EV steps) * Extended ISO
White Balance: AWB / AWBc / AWBw / Daylight / Cloudy / Shadow / Halogen / Flash / White Balance Presets 1, 2, 3, 4 / Color Temperature Settings 1, 2, 3, 4
Self-Timer: 10 seconds, 3 images / 2 seconds / 10 seconds
Continuous Shooting: 9 fps (AFS) / 6 fps (AFC)

Viewfinder and LED
Viewfinder: OLED electronic viewfinder
Viewfinder Coverage: 100%
Viewfinder Magnification:0.78
Viewfinder Dioptre Correction: -1.0 m⁻1/ -4.0 - +2.0 dpt
LCD Type: TFT LCD
LCD Size: 3.2inch
LCD Pixel: 23.3 megapixels
LCD Coverage: 100%
LCD Feature: touch screen, flip screen

File output/input
Record media: SD/SDHC, SDXC
Interface: USB Type C, Super Speed USB3.1 GEN1
Audio/video: HDMI
Wireless: Wi-Fi Bluetooth

Power
Battery: Lithium-ion battery pack (7.4 V, 3050 mAh, 23 Wh)
Battery life: With S-S-R 24105 lens, approx. 400 images (rear monitor), 380 images (LVF), 1,150 images (power-saving LVF mode)

Specification
Color: Black
Size:151.0×114.2×110.4mm
Weight: bare camera 1052g, camera with battery and memory card 1164g

Other
Accessories Interface: earphone, microphone interface
Support Language: Chinese (Simplified), Chinese (Traditional), English, Japanese, French, German, Italian, Korean, Russian, Spanish
Working Temperature-10-40°
Working Humidity: 10-80%
Other Accessories: Body cap, hot shoe cover, eyecup, flash sync socket cover, battery handle connector cover, shoulder strap, battery pack, battery charger, AC adapter, AC power cord, USB connection cable (CC), USB connection cable (AC ), BNC converter cable, cable holder
Note: dual card slot
